Water Pump : 67 lpm
Water Tank Capacity : 650 l and Hose 15 m
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control (Hetronic)
Weight (Without Truck) : 4.645 kg
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (140 bar)
| Piston Side | Theo. Conc. Output (max) | : 70 m³/h |
Theo. Conc. Pressure (max) | : 81 bar | |
Stroke | : 28 Stroke / min | |
| Rod Side | Theo. Conc. Output (max) | : 90 m³/h |
Theo. Conc. Pressure (max) | : 54 bar | |
Stroke | : 36 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 230 mm
Delivery Cylinders Lenght : 1000 mm
Hopper Capacity : 450 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Driven by : PTO or Gear Box
Electric Box : Waterproof and PLC Controlled
