Rod Side | Theo. Conc. Output (max) | 90 m³/h | 90 m³/h |
Theo. Conc. Pressure (max) | 92 bar | 71 bar | |
Stroke | 23 Stroke / min | 34 Stroke / min | |
Piston Side | Theo. Conc. Output (max) | 56 m³/h | 61 m³/h |
Theo. Conc. Pressure (max) | 148 bar | 106 bar | |
Stroke | 14 Stroke / min | 23 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 2100 mm (BCS 21.90) : 1400 mm (BCS 14.90)
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control (Hetronic)
Weight: | 10.500 kg |
Maximum Speed: | 2 km/h |
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (140 bar)
Power: | 185 kW (252 hp) |
Water Pump : 67 lpm
Water Tank Capacity : 550 l and Hose 15 m
Rod Side | Theo. Conc. Output (max) | 90 m³/ h (117,7 yd³ / h) | 90 m³/ h (117,7 yd³ / h) |
Theo. Conc. Pressure (max) | 92 bar (1334 psi) | 71 bar (1029,7 psi) | |
Stroke | 23 Stroke / min | 34 Stroke / min | |
Piston Side | Theo. Conc. Output (max) | 56 m³/ h (73,2 yd³ / h) | 61 m³/ h (79,8 yd³ / h) |
Theo. Conc. Pressure (max) | 148 bar (2146,5 psi) | 106 bar (1537,4 psi) | |
Stroke | 14 Stroke / min | 23 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar (2755,7 psi)
Delivery Cylinders Diameter : 200 mm (7,87’’)
Delivery Cylinders Lenght : 2100 mm (82,6’’) (BCS 21.90) : 1400 mm (55,1’’) (BCS 14.90)
Hopper Capacity : 650 l (171,71 gal)
Hopper Outlet Diameter : 125 mm (5,5’’)
Reducer Output Diameter : 150 mm (6’’)
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control (Hetronic)
Weight: | 10.500 kg (23.148 lbs) |
Maximum Speed: | 2 km / h |
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (135 bar / 1958 psi)
■ Water Pump (67 lpm) (17,7 gpm)
■ Water Tank Capacity 550 l (145.2 gal) and Hose 15 m (49’2’’)
↵
Power: | 185 kW (252 hp) |
| Water Pump: | 67lpm |
| Water Tank Opacity: | 550lt and hose15m |
